Non-Insulated Ring Terminals - Square

(325-D-12)
0
Package Qty: 10
Quantity:

Features
  • MATERIAL: Oxygen free copper strip/tube (electro-tin-plating).
  • RATED CURRENT: Please click here to see the amperage rating table for insulated wires.
  • STANDARDS: UL 486A-468B (File No. E44245), CSA C22.2 (File No. LR-28418), JIS C2805 and JIS C2806
Specifications
  • Stud: 1/2"
  • AWG: 500-600 MCM
  • B: 50.5mm / 1.99"
  • L: 124mm / 4.88"
  • A: 40mm / 1.57"
  • F: 29.5mm / 1.16"
  • E: 36.5mm / 1.44"
  • øD: 37.8mm / 1.49"
  • ød: 28mm / 1.1"
  • ød2: 14mm / 0.55"
  • Wire Size Range for Stranded Wire (mmø|): 242.27-325.00
  • Material (Connector Contact): Oxygen free copper strip/tube (electro-tin-plating)
  • RoHS: RoHS 10
