New Products

  • QUICK LOCKS SPRING PRESSURE WIRE CONNECTORS QLXL-3

    • New shape allows visual inspection of wire insertion condition
    • Double contact spring structure



    Applicable wire

    • Copper solid wire: 12-10 AWG (2.0mm, 2.6mm)
    • Copper stranded wire: 12 AWG (IV 5.5mm2)



    Material

    • Spring: Stainless steel
    • Conductive plate: Oxygen free copper (tin plated)
    • Housing: Polycarbonate

    Ratings: 300V/40A

    Dimensions: 22mm (diameter) x 23mm (length)

    Standard: <PS>E JET

    Number in package: 20 pcs.

  • ECO-FRIENDLY INSULATED POLYCARBONATE SPADE TERMINALS (TMEX)

    The new Polycarbonate type, TMEX, does not include the Dibutyl Tin Compound or Phthalic Acid, but still retains the same stability in manufacturing as Vinyl.



    • Easy to Recycle
    • Non-Corrosive
    • No Heavy Metal Contents,
    • No Emissions of Poisonous Gas
    • RoHS 10 Compliant
    • 600V / -40℃~120℃
    $0.00
  • ECO-FRIENDLY INSULATED POLYCARBONATE RING TERMINALS (TMEX) 24-14 AWG

    The new Polycarbonate type, TMEX, does not include the Dibutyl Tin Compound or Phthalic Acid, but still retains the same stability in manufacturing as Vinyl.



    • Easy to Recycle
    • Non-Corrosive
    • No Heavy Metal Contents,
    • No Emissions of Poisonous Gas
    • RoHS 10 Compliant
    • 600V / -40℃~120℃
    $0.00
  • QUICK LOCKS PUSH-IN WIRE CONNECTORS (QLX SQ & QLX MC SERIES)

    The QLX SQ & QLX MC Series Quick Lock Connectors work by gripping the wires in two different places to prevent slippage while the translucent housing makes it easier to check the connections.

    FEATURES

    • QLX SQ surpass the temperature rise test to 380°C in 15 minutes
    • Reliable, double contacts for a stronger grip
    • Can be used with a 17-19 AWG solid wire

    MATERIAL

    • Connector contact: Copper alloy
    • Housing: Polycarbonate (QLX MC), Liquid-crystal polymer (QLX SQ)
    $0.00
  • QUICK LOCKS PUSH-IN WIRE CONNECTORS (QLX SERIES)

    Quick Locks push-in wire connectors for solid copper wires. Make indoor wire connections by inserting stripped or solid copper wires.

    FEATURES

    • Reliable, double contacts for a stronger grip
    • Simply strip and insert wire for an instant connection
    • Clear translucent housing enables visual inspection of correct wire installation
    • Waved copper contact for easier insertion of wire
    • Can be used with a 12 or 14 AWG solid or stranded copper wire (up to 7 strands)



    MATERIAL

    • Spring: Stainless Steel
    • Connector contact: Oxygen free copper (Tin plated)
    • Housing: Polycarbonate (UL94V2)
    $0.00
  • HEAT-SHRINK BUTT CONNECTORS

    The insulation of HEAT SHRINK RING (SR) and BUTT (SB) consists of a special double layer, high-density polyethylene and polyolefin adhesive. After crimping, the insulation is heated to shrink the outer polyethylene layer and to melt the inner polyolefin liner. This action squeezes out gas while filling all voids resulting in a sealed connection.

    $0.01
  • HEAT-SHRINK RING TERMINALS

    The insulation of HEAT SHRINK RING (SR) and BUTT (SB) consists of a special double layer, high-density polyethylene and polyolefin adhesive. After crimping, the insulation is heated to shrink the outer polyethylene layer and to melt the inner polyolefin liner. This action squeezes out gas while filling all voids resulting in a sealed connection.

    $0.01
  • WIRE TO WIRE IDC (NDB 2018)

    The NDC series is the wire to wire Insulation Displacement Connector (IDC) which eliminates the process of stripping and crimping contacts onto a wire. The NDC series simplifies installation while providing a quick and reliable termination for automotive and industrial market applications. The NDC series is ideal for use with things such as audio cables, lighting, safety systems etc. in automotive applications due to their superior resistance to the difficult conditions in which vehicles must operate. Vehicles of the future will be vastly dependent on technology, and NDC series will be an essential part of those new ventures.

    FEATURES

    • Cost-effective, reliable alternative to crimping and soldering
    • Simple single connection structure
    • No need of wire stripping
    • Fast and easy connection by using pliers
    • Provides dependable connections
    • Multiple connection is possible
    $0.00
  • WIRE TO WIRE IDC (NDC 2018A)

    The NDC series is the wire to wire Insulation Displacement Connector (IDC) which eliminates the process of stripping and crimping contacts onto a wire. The NDC series simplifies installation while providing a quick and reliable termination for automotive and industrial market applications. The NDC series is ideal for use with things such as audio cables, lighting, safety systems etc. in automotive applications due to their superior resistance to the difficult conditions in which vehicles must operate. Vehicles of the future will be vastly dependent on technology, and NDC series will be an essential part of those new ventures.

    FEATURES

    • Cost-effective, reliable alternative to crimping and soldering
    • Simple single connection structure
    • No need of wire stripping
    • Fast and easy connection by using pliers
    • Provides dependable connections
    • Multiple connection is possible
    $0.00
  • WIRE TO WIRE IDC (NDC 2420)

    The NDC series is the wire to wire Insulation Displacement Connector (IDC) which eliminates the process of stripping and crimping contacts onto a wire. The NDC series simplifies installation while providing a quick and reliable termination for automotive and industrial market applications. The NDC series is ideal for use with things such as audio cables, lighting, safety systems etc. in automotive applications due to their superior resistance to the difficult conditions in which vehicles must operate. Vehicles of the future will be vastly dependent on technology, and NDC series will be an essential part of those new ventures.

    FEATURES

    • Cost-effective, reliable alternative to crimping and soldering
    • Simple single connection structure
    • No need of wire stripping
    • Fast and easy connection by using pliers
    • Provides dependable connections
    • Multiple connection is possible
    $0.00
